A Guide to Cannon Bar Works’ Chainsaw Bar Mounts and Adaptor Plates

Cannon Bar Works Ltd. manufactures chainsaw guide bars in many different mount patterns to fit almost all makes and models of chainsaws. In total, Cannon Bar Works has 9 standard chainsaw bar mounts, two of those being “Universal” or “Combination” mounts. Cannon also offers adaptor plates and bushings for a couple of the larger mount patterns to allow them to fit on other makes and models of chainsaws. Below is a breakdown of each mount pattern and any adaptor bushings/plates available for the mounts:

C1 Mount

Cannon’s C1 mount is a “Combination” mount and it is equivalent to Oregon’s A041, K041, A061, A064, A074, A095, and K095 mount patterns and the Stihl 3005 mount. This mount fits most chainsaws on the market that are under 60 CC. The C1 mount will fit on all chainsaws that take our H5, H6, and S5 mounts listed below.

This mount is available in Carver Bars, Pruner Bars, SuperMini Bars, and SuperBars.

Bar lengths available in this mount range from 8” up to 32”.

All bars C1 mount bars come with an oil hole gasket cover.

Fits: Craftsman, Cub Cadet, Dewalt, Dolmar, Homelite, Husqvarna, John Deere, Jonsered, Makita, Maruyama Pole Saws, McCulloch, Olympyk (Oleo-Mac), Partner, Pioneer, Poulan/Poulan Pro, Redmax, Sears, Shindaiwa, Stihl, Skil, Snapper, Solo, Stanley, Tanaka, Toro.

H5  Mount

Cannon’s H5 Mount is equivalent to Oregon’s A095Mount, mostly fitting Husqvarna saws under 60 CC. The H5 Mount is very similar to the H6 mount, but it has a slightly narrower tail. It is also similar to the C1 mount, with a very similar slot, but only the forward two adjusting and oiler holes.

The H5 mount is unique to SuperMini Bars and is available in 12”, 13”, and 15”.

Fits: Cub Cadet, Dolmar, Homelite, Husqvarna, John Deere, Jonsered, Makita, Maruyama Pole Saws, McCulloch, Olympyk (Oleo-Mac), Partner, Pioneer, Poulan/Poulan Pro, Redmax, Sears, Solo, Stanley.

H6 Mount

Cannon’s H6 Mount is equivalent to Oregon’s K095 Mount, mostly fitting Husqvarna saws under 60 CC. The H6 mount is very similar to the H5 mount, but it has a slightly wider tail. It is also similar to the C1 mount with a very similar slot, but only the forward two adjusting and oiler holes.

The H6 mount is unique to SuperMini Bars and is available in 16”, 18”, 20”, 24”, 28”, and 32”.

Fits: Cub Cadet, Dolmar, Homelite, Husqvarna, John Deere, Jonsered, Makita, Maruyama Pole Saws, McCulloch, Olympyk (Oleo-Mac), Partner, Pioneer, Poulan/Poulan Pro, Redmax, Sears, Solo, Stanley.

S5 Mount

Cannon’s S5 Mount is equivalent to Oregon’s A074 Mount and the Stihl 3005 mount, fitting Stihl saws under 60 CC. It is also similar to the C1 mount, but with an open tail and only the rear two adjusting and oiler holes.

The S5 mount is unique to SuperMini Bars and is available in 12”, 14”, and 16”.

Fits: Stihl and Olympk (Oleo-Mac)

G1 Mount

Cannon’s G1 mount is a universal mount, and only available in the SawMiller Bar. The G1 mount fits directly onto chainsaws with 14 mm bar studs, such as the MS 880. Every SawMiller bar comes with two sets of adaptor bushings – one set of bushings (CBW-87577) to bring the 14 mm slot down to 12.1 mm and fit most Stihl saws calling for the Stihl 3003 mount(all saws that the S1 mount fits), and one set of adaptor bushings (CBW-87575) that bring the 14 mm slot down to 9 mm and fit most Husqvarna, Jonsered, Dolmar and Redmaxsaws that call for the Oregon D009 mount(all saws that the H1 mount fits). There are also adaptor plates available for purchase, which serve the same purpose, but are more durable and harder to misplace.

Bar lengths available in this mount range from 44” up to 138”+.

Fits as-is: Dolmar, Stihl

Fits with CBW-87577 adaptor bushings: Stihl saws with 12.1 mm bar studs

Fits with CBW-87575 adaptor bushings: Dolmar, Husqvarna, Jonsered, Makita, Partner, Shindaiwa, Solo saws with 9 mm bar studs

Adaptor Plates available for the G1 mount:

H1 Mount

Cannon’s H1 mount is equivalent to Oregon’s D009 mount, fitting most Husqvarna chainsaws over 60 CC.

The H1 mount is available in Carver Bars, Pruner Bars, SuperMini Bars, and SuperBars.

Bar lengths available in this mount range from 12” up to 84”.

Fits:Dolmar, Husqvarna, Jonsered, Makita, Partner, Redmax, Shindaiwa, Solo

P4 Mount

Cannon’s P4 mount is equivalent to Oregon’s D176 mount, fitting many Echo saws.

The P4 mount is exclusive to the SuperBar and available in length of 16”, 20”, 24”, 28”, and 32”.

Fits:Echo, Fairmont, John Deere, McCulloch, Poulan/Poulan Pro, Redmax, Sears, Skil, Tanaka

S1 Mount

Cannon’s S1 Mount is equivalent to Oregon’s D025 mount or the Stihl 3003 mount and fits onto most Stihl saws between 60 CC and 91 CC. There are many adaptor plates available for the S1 mount to allow it to fit on other makes of chainsaws.

The S1 mount is available in Carver Bars, Pruner Bars, SuperMini Bars, and SuperBars.

Bar lengths available in this mount range from 12” up to 60”.

Fits: Stihl

Adaptor Plates available for the S1 mount:

S2 Mount

Cannon’s S2 Mount is equivalent to Oregon’s D025 mount or the Stihl 3002 mount and fits onto Stihl saws over 100 CC.

The S2 mount is exclusive to the SuperBar and available in lengths from 16” – 84”.

Fits:Dolmar,Stihl

Mount Cross-over Guide:

Don’t know what mount your chainsaw fits? Try our BAR FINDER.
